Grab the included screwdriver and let's start disassembling.
NOTE: Don't forget to set lift-off distance (LOD) to 'High' using the Web Driver
Using the screwdriver, peel & discard the top and bottom mouse skates.
Refer to the image to remove the 5 long screws.
Make sure NOT to apply excess force when separating the shell from the base. Running a card along the crack is helpful for separation.
Perform this step only if you're building the WristLock 8K
Disconnect and separate the battery from the PCB.
Refer to the image to remove the 3 short screws.
Use caution to NOT snap the cable.
Refer to the image to remove the 4 short screws.
Refer to the image and remove the 2 buttons.
That's it! - Proceed to the assembly instructions for your model.
